Kits individual gauges. Fuel level sender will automatically calibrate full on first fill up use with gasoline or diesel fuel only.
Speedhut
Speedhut fuel gauge calibration. Call 801 221 1460 call us. If your sensor is different from the preset ranges you can manually calibrate the gauge. Factory default setting is 240 ohms empty and 33 ohms full. 2 116 inch speedhut series instructions. Our fuel level gauges are programmable they are compatible with any oem or aftermarket resistance range. The fuel level gauge can be manually calibrated to your existing fuel tank sender or you can select one of the preset calibration curves.
Air fuel gauges boost and vacuum gauges clocks fuel level gauges pressure gauges speedometers tachometers temperature gauges voltage gauges. Speedhut series 3 38 inch speedometer instructions. Digital 2 116 inch revolution gauge instructions. Disconnect negative battery cable. 240 ohms empty 33 ohms. Standalone airfuel wideband instructions.
Gauges custom gauges tachometers speedometers gps speedometers boost gauges shift lights gauge pods and gauge pillars by speedhut. Fuel level gauge calibration 1. Fuel level gauge factory default resistance settings are. You will need to program the empty resistance and the full resistance. Fuel level sensor must be attached to gauge during calibration procedures. Digital 2 116 inch programmable fuel level instructions.
No gauge calibration necessary sender is 240ω empty and 33ω full default speedhut fuel level gauge is 240ω empty 33ω full ohms equivalent no gauge calibration necessary sender is 240ω empty and 33ω full note. If sensor is hooked up to gauge gauge will read the resistance of the sensor and display this as a starting point. Digital 2 116 inch airfuel wide band instructions. Connect wiring as above. Make sure fuel level sensor is hooked up to gauge and is at the appropriate empty or full state you wish to calibrate. Follow steps 1 2 above and select manual calibration f see figure 1.
Both empty and full conditions have to be calibrated before the gauge will display the fuel level accurately. Speedhut series gauge instructions. The gauge will exit the calibration menu and will attempt to display the current fuel level. Speedhut tech video 1 fuel level gauge calibration. 2 116 inch 2 58 inch 3 38 inch 4 inch 4 12 inch 5 12 inch. Individual gauges gauge kits.
When setting up your gauge follow the simple calibration setup found in the installation instructions. Pressing and holding button down on this menu will change the resistance of the fuel full setting. This calibration can be done with sensor hooked up or not hooked up to gauge. No calibration necessary on senders with this output.
