Wc t5s were introduced in the 1985 ford model year and 1987 chevy model year. Fox body mustang transmission fluid capacity.
Volvo Xc60 T5 Sport Utility 2 5l L5 Automatic Transmission Fluid 1 Liter Volvo Approval Jws 3324
T5 transmission fluid type. The most important feature of any lubricating fluid is the viscosity. Lubricants are specified to provide the longest service life of the gear box as a system. Atf even provides the connection between the engine and transmission through a hydraulic coupling called a torque converter. The transmission fluid capacity of the t5 is 28 quarts. Most t5 transmission models use dexron ii automatic transmission fluid. Some significant modifications were available beginning around 1985 as the transmission made the transition from the non world class to the world class model.
A4ld approx 95 qts including torque converter approx 3qtys pan and filter service only atf fluid. Do not use gear oil in the t5 transmission since this may damage the blocking ring material. Caution do not mix different bands or types of transmission lubricant. Refer the vehicle owners manual or service manual for lubricant specifications. The lubricant required for wc t5s is automatic transmission fluid atf. Aod approx 12 qts including torque converter approx 5qts pan and filter service only atf fluid.
The t 5s all came with a tag that ids the trans. Automatic transmissions use a special type of oil called automatic transmission fluid or atf. My understanding is that the non world class t 5 use 70 wt gear oil because of a gear difference and bronze syncros but that the world class t 5s use atf fluid. They both take a bit under 3 qts. The wc t 5 came out in about 85 i think so your 84 may be a non wc. Oil type for t5 transmission those are factory recommendations but even the factory changed their minds in the mid late 80s and began using atf in nwc.
This fluid has a number of duties in the transmission including lubrication cooling and clutch application. I use synthetic atf in all my t5s now and have had no issues wc or nwc. The t5 transmission was a 5 speed manual transmission that was first produced in 1980 by borg warner. The t5 is the longest running five speed overdrive standard shift transmission spanning more than 30 years of production. The transmission is quite light with reported weights being between 70 to 75 pounds. T5 approx 28qts syncromesh fluid.
While there are numerous configurations of the t5 because of the large quantities of t5s produced many parts are interchangeable.
