To charge the battery of your x2 transponder slide the x2 racekey onto the back of the transponder and have the racekey connected to a computer or usb adapter by usb cable. These leds light up or flash when power is applied to the racekey to indicate the status of the x2 transponder.
Mylaps Tr2 Transponder Rechargeable For Mx Motocross Includes 1 Year Subscription
Mylaps x2 transponder charging lights. Answer the x2 transponder has an indicator led in the m8 connector. Model car racing demands very small and light transponders. Two different x2 transponder configurations are available. Also when the subscription is expired the led on the x2 transponder will be flashing red fast 5 x per second. Marathons need to handle a high density of competitors. Plug the power adapter into an electrical outlet and place the transponder on the charging unit.
Rechargeable no cabling between components transponder can be eventually charged by connecting the x2 racekey via a usb cable direct power dp all components are connected via cabling to a vehicle 12 vdc supply. We have developed specialized transponders chips for each sport since each has its own unique requirements. Professional car and bike series for example insist on extremely high accuracy. X2 system x2 x2 timing system motorsports bike racing car racing karting motocross stock car racing. When the racekey is connected to mylaps connect all lights are steady blue. The subscription light on the x2 racekey will flash red inactive or green active after the initial display of various colors.
X2 x2 system motorsports bike racing car racing karting motocross snocross stock car racing x2 timing system. A full charge yields a minimum of 4 days use. Mylaps transponders for various sports. The x2 transponder has an indicator light in the m8 connector. The transponders led will flash red indicating that the transponder is charging. The signals differ slightly depending on whether the racekey is docked in the racekey mount as on direct power installations or docked on the x2 transponder itself as a rechargeable transponder.
After about 16 hours a steady green led indicates that the transponder is fully charged. When the x2 direct power transponder is installed in the vehicle and the x2 racekey is connected. What does the blinking of the indicator light on the x2 transponder mean when used as a direct power.
